Self-Aligning High-Current Interconnects for Medical & Industrial Hardware

We engineer self-aligning Magnetic Pogo Connectors tailored for wearables, patient medical monitors and industrial DAQ systems. Our product lineup supports continuous loads from 2A up to 10A+ across a 3.3V–24V operating voltage range. We offer customizable contact plating up to 30μ” gold over beryllium copper to block sweat and chemical electrochemical corrosion. Fully sealed housing designs maintain steady power and signal transmission under harsh shock, vibration and humid working conditions.

Form-Fit Mechanical Compatibility with Mill-Max Reference Footprints

Precision hardware integration requires consistent magnetic mating force and tight dimensional tolerances. Jiatel supplies form-fit drop-in mechanical replacements compatible with legacy Mill-Max footprint layouts. Our pin layouts, magnet positioning and outer housing dimensions match standard reference specs for direct PCB mounting with no board redesign required. We never rely on unvalidated digital mockups for production. All tolerance checks are performed against official [Technical Datasheets] and verified [2D Footprint Specs], eliminating field failures caused by polarity misalignment or mismatched mating geometry.

Dedicated NPI Engineering & 50,000-Cycle Blind Mating Durability

Our senior NPI engineering team reviews every customer housing and assembly constraint to deliver reliable blind self-mating rated for up to 50,000 insertions. Custom magnet polarity mapping eliminates short-circuit risks, with sub-millimeter tolerances locked in prior to SMT/THM PCB assembly. If you require a custom magnetic connector for wearable or medical equipment, submit your specs to our engineering queue for fast resource allocation and sample evaluation.

Technical Specifications and Performance Matrix

Request Engineering Drawings & Custom Technical Support

Our technical team supports custom magnetic geometries and specialized quick-install mounting designs for procurement and hardware teams worldwide. We maintain a strict 12-hour fast response SLA, delivering fully validated, production-ready PDF engineering drawings upon request. To join our priority technical validation pipeline and share your custom magnetic connector parameters: Request Engineering Support

Disclaimer: Our mechanical footprint-matched magnetic connectors share identical PCB mounting geometry with reference Mill-Max layouts. Contact plating thickness and long-term corrosion performance can be tailored per your project budget and reliability requirements, and may differ from original OEM specs.
