ZIF FPC/FFC Connectors: High-Density Solutions for Display & Data

Jiatel provides a comprehensive line of Flexible Printed Circuit (FPC) and Flexible Flat Cable (FFC) Connectors, essential for modern, high-density, and miniaturized electronic applications.Notably, our connectors specialize in Zero Insertion Force (ZIF) and non-ZIF solutions, ensuring secure, reliable, and high-speed data transmission in devices like displays, cameras, and scanners.

1. Precision & Flexibility: Contact and Pitch Options

We offer precise solutions to meet every complex routing requirement, from ultra-fine pitch (0.5mm) to standard 2.54mm pitch.

Parameter Options We Provide Design Flexibility
Pitch Spacing 0.5mm, 1.0mm, 1.25mm, 2.54mm Covers current industry standards and requirements for product miniaturization.
Contact Direction Up Contact (Top-side connection), Down Contact (Bottom-side connection), Vertical Contact (Dual-side contact) Simplifies complex PCB routing and optimizes space utilization in layered designs.
Locking Mechanism (ZIF) Pull-out Slider, Flip-back Slider Consequently, this ensures Zero Insertion Force (ZIF) operation, protecting the fragile FFC/FPC cable from damage during mating.

2. Materials & Mounting: Reliability for SMT Assembly

Our connectors are engineered for durability, stability, and compatibility with high-volume automated manufacturing processes.

Core Reliability Features

  • Contact Material: We utilize high-resilience Phosphor Bronze for superior electrical conductivity and mechanical cycle life.
  • Contact Plating: We offer Gold Plating over Nickel (for maximum reliability and low resistance) or Tin Plating over Nickel (for cost-effective solutions).
  • High-Temperature Housing: Furthermore, this ensures compatibility with modern SMT reflow soldering processes.

Mounting Versatility

We provide multiple mounting styles to integrate seamlessly into your PCB design:

  • Right Angle SMT Mounting: The most common style for space-saving, low-profile horizontal connections.
  • Vertical SMT Mounting: Ideal for stacking and vertical board-to-board or display connections.
  • Through-hole mounting (THM): Available for standard 1.25mm pitch, offering enhanced mechanical robustness.

3. Manufacturer Commitment

Jiatel manufactures FPC/FFC Connectors to meet most global market demands, emphasizing quality and rapid service.

Moreover, if none of the options listed above are what you’re looking for, or if you require a custom configuration (e.g., specific pin count, unique cable shape), our engineering team is ready to assist.

Contact our sales expert immediately. We guarantee a reply and support within 12 hours to accelerate your project schedule.
