Custom Pin Header & Female Header: High-Density Board-to-Board Solutions

Jiatel stands as a leading manufacturer of connectors and cable assemblies in China, specializing in highly reliable Board-to-Board Connectors. Our most versatile product line includes custom Pin Headers and Female Headers, engineered to meet the demanding requirements of high-density and automated PCB assembly.

1. Precision & Versatility: Technical Specifications

We transform the flexibility of the Pin Header system into reliable, high-performance interconnects through meticulous material selection and manufacturing precision.

Technical Parameter Jiatel Customization Options Engineering Relevance
Pitch Spacing 0.8mm, 1.0mm, 1.27mm, 2.0mm, 2.54mm High-Density Ready: Supports product miniaturization and all industry standards.
Pin Count Single Row: 01~64 Pin; Double Row: 02~128 Pin Deep Customization: Covers all circuit board design needs.
Plating Options Gold plating (Gold Flash, Au1μ”, Au3μ”, Au5μ”) or Tin plating. Signal Integrity: Precisely match plating thickness to signal reliability and durability requirements.
Insulator Material SMT: LCP, Nylon6T (High-temp); THM: PBT Reflow Soldering Safe: Ensures stability during high-temperature Surface Mount Technology (SMT).
Mounting Types Straight Through-Hole Mount, Surface Mount, Locating Post SMT Mount. Design Flexibility: Supports both robust mechanical connections (THM) and space-saving automation (SMT).
Mating Direction Top Entry, Side Entry, Bottom Entry. PCB Routing: Provides optimal design freedom for complex board stacking and cable routing.

2. Optimized for Automated Assembly

Our headers are designed to enhance your production efficiency. They can be used for both permanent (soldering) and removable Board-to-Board connections (paired Male/Female).

Packaging for High-Speed Pick-and-Place

We offer packaging solutions tailored for automated manufacturing processes:

  • Tape & Reel (T&R): Available with pick-up cover or film—essential for high-speed SMT assembly and maximum efficiency.
  • Other Options: Loose in bag, Tube, and Tray packaging.

Lead Time and Support

  • Sampling: Samples provided within 5 to 8 business days.
  • Lead Time: Production lead time is approximately 2 weeks from order confirmation.
  • MOQ: Standard MOQ is 1,000 pieces; 5,000 pieces for low pin counts (ensuring cost-effectiveness).

3. Dedicated Customer Support & Customization

All the above questions are merely a starting point. If you require a tailored solution or want to customize a Pin Header or Female Header, our engineering team is ready to assist.

Jiatel sales team will help you. Contact us immediately for a tailored solution or consultation!
