Product Definition

The Jianniu Connector belongs to the IDC (Insulation Displacement Connector) family, characterized by its latch-free simplified design. It achieves stable signal/power connection between PCBs through square pins directly crimped with IDC cables. With a compact structure and significant cost advantages, it’s the go-to choice for low-to-medium speed connection scenarios.

Key Advantages

✅ Minimalist Design, Easy Installation
  • Eliminates the latches of traditional horn connectors; single/double row straight plug design requires no additional locking tools, saving 50% installation time
  • Compatible with 主流 pitch sizes 1.27mm/2.0mm/2.54mm, fitting 90% of standard IDC cables on the market
✅ Reliable Performance, Versatile Applications
  • Terminals use phosphor bronze with gold plating (50μin nickel base + 3μin gold), contact resistance ≤20mΩ, supporting 0.5A-3A current transmission
  • Flame-retardant PA66 housing (UL94V-0), operating temperature -40℃~+105℃, suitable for indoor/outdoor equipment environments
✅ Cost-Effective, Flexible Options
  • 60% cheaper than horn connectors of the same specification, significant cost advantage for bulk purchases
  • Offers three mounting types: SMT, DIP, and bent pin (90°/180°), adapting to high-density PCBs and 3D cabling needs

Application Scenarios

🔌 Consumer Electronics
Mobile/tablet camera module connections | Laptop battery interfaces | Smart home control board signal transmission
🔧 Industrial Equipment
PLC module expansion | Sensor data collection | Small industrial computer motherboard interconnection
💡 LED Lighting
LED strip power connections | Display module splicing | Backlight panel signal transmission
🛠️ DIY/Maker Projects
Raspberry Pi/Arduino expansion boards | Robot control boards | Prototyping circuit board quick docking

Selection Guide

Application Type
Recommended Specification
Typical Use Cases
Miniaturized Design
1.27mm pitch + SMT
Mobile devices/wearables
High-Current Transmission
2.54mm pitch + through-hole
Industrial power/BMS
3D Cabling
90° Bent Pin Design
Multi-layer PCBs/spatial constraints
Extreme Environments
LCP material + high-temperature resistance
Automotive electronics/outdoor equipment

Purchase Information

📏 SpecificationsPin count: 2Pin-60Pin (customizable)Contact method: IDC crimping (no wire stripping needed)Certifications: RoHS 2.0 compliant, select models with UL certification
🚀 Buying Tips
  1. Match mounting type with PCB process (SMT/DIP)
  1. Choose pitch based on current requirements (1.27mm ≤1A, 2.54mm ≥3A)
  1. Request samples for insertion/extraction force and contact resistance testing for bulk orders
💬 FAQs
Q: How to distinguish Jianniu from Horn Connectors?
A: Jianniu has no side latches, relying on PCB soldering for fixation; Horn connectors have mechanical latches, ideal for vibration environments – choose based on usage scenarios.
Q: Can pin configurations be customized?
A: Yes, supports single/double row staggered pins and anti-misinsertion notches – contact our team with your design drawings.
